Flow Fusion Light
2866.67
- +
Details

Built extensively with Porcher Skytex 27g and light weight dyneema risers, the Fusion Light is livelier, lighter, more compact and has a more direct handling and feel.

We’ve managed to improve the speed range and the overall performance slightly, making our EN C glider even better. The fun factor and real performance of this glider is truly amazing. Like it’s original brother, Fusion Light is a game changer!

We have introduced a pulley on the floating B riser, which gives a true 2-liner feel as well as lighter rear riser control, integrating the hybrid 3-2 line layout in harmony and efficiency.

We believe the Fusion Light will be the perfect glider for many adventures, hike & fly missions or just the perfect companion for your next flight.

We are happy that the Fusion Light is certified, as it is the favourite glider of our team pilots, and it can now be appreciated and enjoyed by intermediate pilots who like the practicality of a 3 liner glider and the efficiency of a purebred 2 liner racer.

HYBRID 3 TO 2-LINE LAYOUT

The hybrid 3-2 line layout brings drastic drag reduction in comparison
to the traditional 3 lines layout. Ultimately translating to increased gains in performance.
  • Better glide
  • More solidity
  • More efficiency
  • Higher top-end speed
  • Increased solidity at higher speeds

ALIGHTED UNDISTURBED AIR FLOW

alighned-airflow
The Fusion was designed in a way where every cell is aligned to true airflow so there is less disturbance by the inherent billowing effect found on paragliders.



The canopy twist and washout on the wingtips further reduce drag and improve the lift coefficients and aerodynamics on the Fusion.

PITCH STABLE SHARK NOSE AIRFOIL

Pitch-stable-shark-nose-aifoil

Our solid shark nose profile is a pitch stable airfoil which means:

  • Fewer oscillations
  • More efficient glides
  • Solidity at higher speeds
  • Higher Comfort

OPTIMIZED INTERNAL STRUCTURE

Each cell and diagonals were structurally dimensioned and thoroughly computer analyzed to offer the most suitable chord and span-wise sail tension.
The result is a canopy with less attachment points but more taught and rigid offering just enough flex characteristics to give the ideal feedback.
A well-tensioned sail is especially important at higher speeds to improve solidity and resistance against collapses.
Opmized-internal-structure-(1)
Technical Specs
More Information
Brand Flow
Specs
S M ML
FLAT AREA 22.95 m2 24.45 m2 26.3 m2
PROJECTED AREA 19.56m2 20.89m2 22.47m2
FLAT WINGSPAN 12.07m 12.48m 12.94m
PROJECTED SPAN 9.73m 10.06m 10.43m
ASPECT RATIO 6.35 6.35 6.35
PROJECTED AR 4.86 4.86 4.86
MAX CHORD 2.38 2.45 2.54
NUMBER OF CELLS 68 68 68
GLIDER WEIGHT 3.6kgs 3.8kgs 3.95kgs
TAKE OFF WEIGHT 72-92 kgs 80-103 kgs 92-115 kgs
CERTIFICATION LTF/EN C LTF/EN C LTF/EN C
Material
CANOPY FABRIC CODE SUPPLIER
Upper Surface Skytex 27 soft Porcher
Bottom Surface Skytex 27 soft Porcher
Supported Ribs 27 hard Porcher
Unsupported Ribs 27 hard Porcher
Profile Reinforcement 2.5/1.8/ Nylon rods Porcher
Thread 210D/3, 420D/3 Coats Thread
SUSPENTION LINES FABRIC CODE SUPPLIER
Upper Cascades Edelrid 8000U 130/090/070/050kg
Edelrid 9200 030kg
EDELRID
Middle Cascades Edelrid 8000U 190/130/090/070/050kg
Edelrid 9200 030kg
EDELRID
Main Lines Edelrid 8000U 360/190/130/050kg
Liros DSL 140kg
EDELRID
LIROS GmbH
RISERS FABRIC CODE Connectors
Shackles Maillon Rapide ANSUNG
Riser Webbing 12mm zero stretch polyester webbing Guth & Wolth GMBH
Pulleys Pulleys Ronstan ball bearing Ronstan
Package Includes

Flow Paraglider Rucksacks

  • Choose a size: XL, L, M, S and XS
  • Comfortable with waist strap and adjustable chest strap
  • Colours: Lime/Black

Flow Cap

Repair kit

Colors

OCEAN

SUNRISE

Availability
2-6 weeks
